Courtesy Light 1005 Brass PVD

Courtesy Light 1005 Brass PVD

1005WH IP65

€112,50 EUR
€112,50 EUR
Sale Sold out
Tax included. Shipping calculated at checkout.
LED Light Color
Voltage

A slim surface-mounted LED courtesy light in AISI 316 stainless steel with a brass PVD finish, for steps, hallways, cabins and exterior decks on boats and yachts. Available in white, red & white, red or blue, each as 12 V or 24 V version. Only 0.3 W, CRI above 90, IP65 and 82 × 20 × 6 mm.

  • 0.3 WPower consumption
  • 4 coloursWhite, Red & White, Red, Blue
  • 10–30 V DC 12 V and 24 V systems
  • IP65Interior and exterior
  • Brass PVDMaterial

Where to use it
  • Steps
  • Hallways
  • Cabins
  • Cockpit
  • Exterior decks

Discreet orientation and courtesy lighting on board, below deck and on deck. White gives clear illumination, and red preserves night vision in cabins, cockpits and on exterior decks after dark. With IP65 and PVD-coated AISI 316 stainless steel, the light suits interior and exposed exterior positions alike. At 0.3 W and with an LED lifespan of more than 50,000 hours, it is suited to long operating hours, also on battery-powered systems.

Specifications

Light

Light coloursWhite, Red & White, Red, Blue
Colour renderingCRI >90

Electrical

Supply voltage10–30 V DC
Power consumption0.3 W
Current at 12 Vapprox. 25 mA
Current at 24 Vapprox. 13 mA

Mechanical

MaterialBrass PVD
Ingress protectionIP65

Installation and dimensions

Surface-mounted on flat surfaces, so no cutout is needed. Suitable for refits and new builds.

Choose the 12 V version (10–16 V) or the 24 V version (20–30 V) to match the on-board supply. The integrated LED driver keeps the light output stable and free of flicker.

Versions and order numbers
Order no.Version
1005WH IP65White Light / 10-16V
1005WH IP65 24VWhite Light / 20-30V
1005REWH IP65Red & White Light / 10-16V
1005REWH IP65 24VRed & White Light / 20-30V
1005RE IP65Red Light / 10-16V
1005RE IP65 24VRed Light / 20-30V
1005BL IP65Blue Light / 10-16V
1005BL IP65 24VBlue Light / 20-30V

Available with white, red & white, red or blue light, each as 10–16 V or 20–30 V version. Specify light colour and voltage when ordering.

Frequently asked questions

What is the Courtesy Light 1005 used for?
For discreet orientation and courtesy lighting on steps, in hallways and cabins and on exterior decks. With IP65 it suits both interior and exterior positions.

Which light colours are available?
White, red & white, red and blue. Red light preserves night vision in cabins, cockpits and on deck after dark.

Is there a 12 V and a 24 V version?
Yes. The 12 V version runs on 10–16 V, the 24 V version on 20–30 V. Please specify the voltage when ordering.

Can it be used outdoors?
Yes. It is rated IP65, dust-tight and water-resistant, and made of PVD-coated AISI 316 stainless steel for marine use.

How much power does it use?
Only 0.3 W. That makes it suitable for continuous operation, also on battery-powered systems.

How is it installed?
It is surface-mounted on a flat surface, so no cutout is needed. At 82 × 20 × 6 mm it fits refits and new builds alike.

Can the light source be replaced?

No. The LED is permanently built into the light and cannot be replaced.
